FRAME SET
FRAME Intense trail full suspension frame, 6061 heat-treated aluminum, smooth welded, SRAM UDH, Boost spacing (12x148 / 15x110)
FORK SR Suntour Zeron 35 Boost fork, 150mm travel
REAR SHOCK SR Suntour Edge-EVO 3CR rear shock
HEADSET Sealed bearing aluminum Aheadset
BAR / STEM
HANDLEBAR 6061-T6 butted aluminum handlebar, Intense design
STEM 3D-forged 6061 aluminum stem, 31.8mm clamp
GRIP Dual density grips with alloy lock-on, Intense design
WHEEL SET
TIRE Maxxis 29x2.4 New Forekaster, Foldable, 60tpi, EXO/TR
RIM WTB I30 TCS 2.0 rim, 32-hole, anodized black
FRONT HUB Formula DC-711 front hub, 15mm axle
REAR HUB Formula DHT 148 rear hub, 12mm axle
SPOKE Stainless steel spokes, 14G
SHIFTING DRIVE TRAIN
CRANKSET Shimano CUES crankset, 32T
BOTTOM BRACKET Shimano sealed bottom bracket
REAR SHIFTER Shimano SL-U6000-11R, 11-speed Rapidfire shifter
REAR DERAILLEUR Shimano CUES Shadow Plus rear derailleur, 11-speed
CASETTE / FREEWHEEL Shimano CUES cassette, 11-speed, 11–50T
CHAIN Shimano Linkglide chain, 11-speed, with quick-link
BRAKES
FRONT BRAKE Tektro HD-M275 hydraulic front disc brake, 180mm rotor
REAR BRAKE Tektro HD-M275 hydraulic rear disc brake, 180mm rotor
SEATING
SADDLE Intense Trail saddle, dual density base, cro-mo rail
SEAT POST AL-7050 T6 3D-forged alloy seat post
SEAT CLAMP Anodized black seat clamp, forged aluminum lever, 36.4mm
